  • Front and rear installation, can be completely front dismantled;
  • High-strength aluminum alloy box, not easy to deform;
  • Excellent heat dissipation performance and high splicing accuracy;
  • Floating connector, good position tolerance, low stress;
  • Universal power supply, standard cable interface, convenient and reliable;
  • The system layout is simple, reliable and cost-effective;
  • Modular design, high cabinet integration;


  • Indoor small pitch LED video wall
    The visual effect in the real environment
    HDR——High-Dynamic Range

    Compared with ordinary images, it can provide more dynamic range and image details.
    According to LDR (Low-Dynamic Range) images with different exposure times, the final HDR image is synthesized by using LDR images with the best details corresponding to each exposure time. Can better reflect the visual effect in the real environment. In addition to the ordinary RGB information, each pixel also has the actual brightness information of the point.
    Ordinary graphics files only have a grayscale range of 0-255 per pixel, which is actually not enough.


  • Indoor small pitch LED video wall
    Accurate color management system
    Non-linear color coordinate transformation coefficient
    A precise color management system is adopted. After the video is decoded by the LED control system, a secondary filter display algorithm is added to perform a point-by-point 16-bit color correction on each light-emitting diode of the display screen.
    The continuous improvement of the display effect is achieved by constructing a nonlinear correction curve and a color coordinate transformation coefficient matrix. Various important indicators such as color reproduction, color temperature adjustment range, brightness uniformity, omaticity uniformity, refresh rate, frame change frequency, etc., All meet the standards of broadcasting and television.
  • Indoor small pitch LED video wall
    Rich color transition and natural
    High gray level display image effect
    The LED display uses high-quality black surface LED lights to increase the brightness of the light while reducing the brightness of the screen when it is black.The unique black mask processing technology greatly improves the screen contrast.
    Gray scale is the so-called color scale or gray scale, which refers to the degree of brightness, the number of levels that any color changes from dark to bright; LED small-pitch display screens reach 16bit gray scale performance, and display gray scale performance at low brightness It is still intact; the higher the gray level, the higher the level of picture and the higher the vividness of the picture, and the more details of the image can be displayed without loss of information.

See all Specs

  • LED specification
    1. LED configuration

      SMD

      Pixel pitch

      1.25 / 1.56 /1.875 /2.5

    2. Pixel density (point/m2)

      640000 / 409600 / 284444 / 160000

      IP Level

      IP30

    3. Brightness

      600-800

      Color temperature (K)

      3000-10000

    4. Viewing angle (H/V)

      160 / 140

      Deviation of LED luminance center

      <3%

    5. Brightness uniformity

      >=98%

      NTSC Color gamut

      >=120%

    6. Contrast ratio

      5000:1

      Refresh rate @60Hz

      >=3840

  • Power
    1. Chromaticity uniformity (after correction)

      +-0.003Cx,Cy within

      Power consumption (max ; avg)/m2

      600W ; 400W

    2. Input voltage (V)

      AC 100 ~ 240V (50-60 Hz)

  • Environment
    1. Operating temperature (·C)

      -20 ~ 40

      Operating humidity(RH)

      10 - 90%

    2. Storage temperature (·C)

      -30 ~ 60

      Storage humidity (RH)

      10 - 80%

  • Installation way
    1. Installation

      Front / Rear
